Norco Search XR A Suspension 2023
2023 Road
Estimate price |
2,399$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork Suntour GVX
-
Groupset GRX 800, GRX 600 -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
154cm - 165cm
52cm
162cm - 172cm
55cm
169cm - 180cm
58cm
177cm - 188cm
61cm
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Butted Aluminum, Smooth Welds
Suspension Fork
SR Suntour GVX Gravel, 50mm Travel, Lockout
Drivetrain
Rear Derailleur
Shimano GRX RD-RX812 Shadow RD+
Front Derailleur
-
Shift Levers
Shimano GRX ST-RX600
Cassette
Shimano Deore CS-M5100, 11-42T, 11 Speed
Crank
FSA Omega Modular, 40T, 170mm (50.5), 172.5mm (53, 55.5), 175mm (58, 60.5)
Bottom Bracket
FSA BB386EVO for BSA
Chain
KMC X11
Pedals
City Resin
Wheels
Front Hub
Bear Pawls Sealed Bearing, 12x100mm, 6 bolt
Rear Hub
Bear Pawls Sealed Bearing, 12x142mm, HG, 6 Bolt
Rims
Alloy Tubeless Pinned, 28H, 23mm ID
Tires
Front: Vittoria Terreno Dry, 40mm, Graphene 2.0, Rear: Vittoria Terreno Dry, 40mm, Graphene 2.0
Brakes
Brakes
Front: Shimano GRX BR-RX400, Resin Pads, Rear: Shimano GRX BR-RX400, Resin Pads
Brake Levers
Shimano GRX RX600 Hydraulic
Cockpit
Stem
Norco SL Aluminum
Handlebar
Norco Super Flare Aluminum, 16deg Flare, 42cm (45.5, 48, 50.5), 44cm (53, 55.5), 46cm (58, 60.5)
Grips
Griptacular Shockproof Tape
Headset
Integrated Sealed Bearing
Seat
Saddle
Selle Royal Gravel with Cutout
Seatpost
X-Fusion Manic Gravel 50mm Dropper, 27.2mm, Drop-Bar Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.49 mm | 1.51 mm | 1.53 mm | 1.56 mm |
| Bottom Bracket Height | 286.5 mm | 286.5 mm | 289 mm | 291.5 mm | 291.5 mm |
| Front Center | 624 mm | 634 mm | 643 mm | 652 mm | 661 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 85 mm | 83 mm | 82 mm | 80 mm | 78 mm |
| Stack | 558 mm | 578 mm | 595 mm | 612 mm | 632 mm |
| Reach | 384 mm | 389 mm | 394 mm | 399 mm | 404 mm |
| Top Tube Length | 558 mm | 571 mm | 585 mm | 598 mm | 613 mm |
| Seat Tube Angle | 72.75 ° | 72.5 ° | 72.25 ° | 72 ° | 71.75 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 580 mm |
| Head Tube Angle | 69.25 ° | 69.5 ° | 69.75 ° | 70 ° | 70.25 ° |
| Head Tube Length | 95 mm | 115 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 429 mm | 431 mm | 434 mm | 436 mm | 439 mm |
| Wheelbase | 1044 mm | 1057 mm | 1069 mm | 1081 mm | 1093 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 65 mm | 62 mm | 62 mm |
| Standover Height | 683 mm | 711 mm | 741 mm | 771 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 154 cm | 162 cm | 169 cm | 177 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 180 cm | 188 cm | 194 cm |
About this model
Search XR A Suspension belongs to the Norco Search model. Norco released 121 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Norco Search XR Flat Bar 2023 is the cheapest bike model and costs 1349$. Norco Search XR S1 700c 2023 is the most expensive one and costs 3299$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Norco released this model in 2023, its price was 2399$. Comparing this to the average Gravel bike price, we see that the price is 2.63% lower.
Overview of components
Fork
The Suntour GVX is included from the factory. It has a travel distance of 50mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Search XR A Suspension 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Search XR A Suspension is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 154 cm – 194 cm (5.05 ft – 6.36 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Norco model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
