Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
154cm - 165cm
52cm
162cm - 172cm
55cm
169cm - 180cm
58cm
177cm - 188cm
61cm
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Butted Aluminum, Smooth Welds
Suspension Fork
Full Carbon, Through Axle
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810 Shadow RD+
Front Derailleur
Shimano GRX FD-RX810
Shift Levers
Shimano GRX ST-RX600
Cassette
Shimano 105 CS-R7000, 11-34T, 11 Speed
Crank
FSA Omega Modular 46/30 AGX+, 170mm (49, 52cm), 172.5mm (55, 58cm), 175mm (61cm)
Bottom Bracket
FSA BB386EVO for BSA
Chain
KMC X11
Pedals
City Resin
Wheels
Front Hub
Bear Pawls Sealed Bearing, 12x100mm, 6 bolt
Rear Hub
Bear Pawls Sealed Bearing, 12x142mm, HG, 6 Bolt
Rims
Alloy Pinned, 28H, 23mm ID
Tires
Front: Vittoria Terreno Dry 700x40c Graphene 2.0, Rear: Vittoria Terreno Dry 700x40c Graphene 2.0
Brakes
Brakes
Front: Shimano GRX BR-RX400, Resin Pads, Rear: Shimano GRX BR-RX400, Resin Pads
Brake Levers
Shimano GRX RX600
Cockpit
Stem
Norco SL Aluminum, 31.8mm Clamp, 70mm (49), 80mm (52), 90mm (55), 100mm (58), 110mm (61)
Handlebar
Norco Super Flare Aluminum, 16 Degree Flare, 40cm (49), 42cm (52), 44cm (55), 46cm (58, 61)
Grips
Griptacular Shockproof Tape
Headset
Sealed Cartridge Bearing
Seat
Saddle
Selle Royal Gravel with Cutout
Seatpost
Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.49 mm | 1.51 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 276.5 mm | 276.5 mm | 279 mm | 281.5 mm | 281.5 mm |
| Front Center | 605 mm | 615 mm | 624 mm | 634 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 76 mm | 74 mm | 72 mm | 71 mm |
| Stack | 543 mm | 563 mm | 580 mm | 598 mm | 618 mm |
| Reach | 374 mm | 379 mm | 384 mm | 389 mm | 394 mm |
| Top Tube Length | 530 mm | 543 mm | 556 mm | 569 mm | 583 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 580 mm |
| Head Tube Angle | 69.75 ° | 70 ° | 70.25 ° | 70.5 ° | 70.75 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 424 mm | 426 mm | 429 mm | 431 mm | 434 mm |
| Wheelbase | 1017 mm | 1030 mm | 1042 mm | 1055 mm | 1067 mm |
| Bottom Bracket Drop | 77 mm | 77 mm | 75 mm | 72 mm | 72 mm |
| Standover Height | 675 mm | 703 mm | 733 mm | 764 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 154 cm | 162 cm | 169 cm | 177 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 180 cm | 188 cm | 194 cm |
About this model
Search XR A1 belongs to the Norco Search model. Norco released 121 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Norco Search XR Flat Bar 2023 is the most economical model, with a starting price of 1349$. Norco Search XR S1 700c 2023 on the other hand costs 3299$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 2099$. Doing a quick comparison, we notice that Search XR A1 price is 17.29% smaller than the average cost of a Gravel bike.
Search XR A1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Search XR A1 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Search XR A1 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Norco Search XR A1 bike has 5 sizes, in the range of 154 cm – 194 cm (5.05 ft – 6.36 ft). In short, it won’t be difficult to find the right one for you.
