Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 40mm -
Fork SunTour XCT
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 1 × 6 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight aluminum low standover frame
Suspension Fork
SR Suntour XCT Jr. coil spring suspension 40mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano RD TZ 50 direct mount type
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano TZ20 14-28T 6-Spd
Crank
Aluminum narrow-wide 28T 3-pc crankset - Black
Bottom Bracket
Cartridge bearing square taper BB
Pedals
Resin black Jr. flat pedal 9/16" w/bearing"
Wheels
Front Hub
KT 36H MTB hub w/ball bearing
Rear Hub
KT 36H MTB rear hub w/ball bearing
Rims
Aluminum 20" MTB"
Tires
20" x 2.125"" with MTB tread"
Brakes
Brakes
Tektro alloy V-Brake with linear spring
Brake Levers
Tektro Jr. MTB alloy/resin front and rear levers w/reach adjust
Cockpit
Stem
Kalloy 35mm ext., 1-1/8" threadless MTB"
Handlebar
Jr. MTB aluminum 600mm wide x 30mm rise
Grips
Jr. MTB type, soft krayton rubber
Seat
Saddle
Norco Jr. MTB saddle with cutaway design
Seatpost
Aluminum with micro adjust top, 250mmx27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | N/A |
|---|---|
| Stack Reach Ratio | 1.26 mm |
| Bottom Bracket Height | 255 mm |
| Front Center | 527 mm |
| Rake | 39 mm |
| Stack | 411 mm |
| Reach | 326 mm |
| Top Tube Length | 478 mm |
| Seat Tube Angle | 70 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 339 mm |
| Wheelbase | 866 mm |
| Bottom Bracket Drop | 5 mm |
| Standover Height | 446 mm |
| Front Travel | 40 mm |
| Wheels | 20" |
Model Overview
Storm 2.2 completes the Norco Storm model. There are 177 frames that carry this model name. You can easily view all of the Norco Storm frames models from 2017, here.
Model range prices
Norco Storm 2.3 2017 is the most affordable frame of this model and has a price of 269$. On the other hand, Norco Storm 4.1 2017, is the most expensive and costs 449$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Mountain frames
According to our calculations, the average cost of a Mountain frame that is reliable is 514$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
This frame was released in 2017 and its price was 329$. Doing a quick comparison, we notice that Storm 2.2 price is 56.23% lower than the average cost of a Mountain frame.
Overview of components
Fork
The SunTour XCT is included from the factory. It has a travel distance of 40mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Brakes
When you want to stop the bike in time, the brakes are vital. The Storm 2.2 has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
