Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Factory Float 36
-
Groupset XT, e*thirteen -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: 27.5. Rear wheel travel: 130.
Suspension Fork
Fox Factory 36 Float 140mm 27.5 (Black)
Rear Shock
Fox Float X Factory 190x45
Drivetrain
Rear Derailleur
Shimano XT 12spd
Shift Levers
Shimano XT 12spd
Cassette
Shimano XT 10-51T 12spd
Crank
E13 Helix 32t 170mm
Bottom Bracket
E13
Chain
KMC 12spd
Wheels
Rims
Stans Flow Mk4 + Hope Pro 4 (Black)
Tires
Maxxis Minion DHF 2.5 3C Exo / DHR II 2.4 Exo 27.5
Brakes
Brakes
Shimano XT Trail 203/180
Cockpit
Stem
Hope M35 x 35mm Black
Handlebar
Renthal FatBar M35 800mm
Grips
Strange Grappler Lock-On
Headset
Cane Creek 49mm for Tapered Steerer
Seat
Saddle
SDG Strange Bel Air III
Seatpost
Fox Factory Transfer 175mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.3 mm | 1.24 mm | 1.24 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 763 mm | 785 mm | 805 mm | 829 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 131 mm | 130 mm | 131 mm | 131 mm |
| Stack | 600 mm | 609 mm | 609 mm | 627 mm |
| Reach | 453 mm | 470 mm | 491 mm | 506 mm |
| Top Tube Length | 601 mm | 621 mm | 641 mm | 661 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1202 mm | 1224 mm | 1244 mm | 1268 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 698 mm | 718 mm | 736 mm | 763 mm |
| Rear Travel | 130 mm | 130 mm | 130 mm | 130 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Five Evo Factory is an Orange Five model. There are 27 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Orange Five Evo S 2022 is the most affordable bike of this model and has a price of 4447$. On the other hand, Orange Five EVO SE 2022, is the most expensive and costs 7400$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 6989$. Comparing the average cost of a Trail bike to this one, you will see that Five Evo Factory price is 153.04% more expensive.
Five Evo Factory components
Fork
The Fox Factory Float 36 is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Orange Five Evo Factory bike has the Fox Float X Factory 190×45 model installed, and has a travel of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Five Evo Factory bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Orange Five Evo Factory bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Orange Five Evo Factory comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
