Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike Ultimate
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: 27.5. Rear wheel travel: 130.
Suspension Fork
RockShox Pike Ultimate 140mm 27.5
Rear Shock
RockShox Super Deluxe Ultimate 190x45
Drivetrain
Rear Derailleur
SRAM GX Eagle 12spd
Shift Levers
SRAM GX Eagle 12spd
Cassette
SRAM XG 1275 10-52t Eagle
Crank
SRAM GX Eagle 32t
Bottom Bracket
SRAM DUB
Chain
SRAM SX Eagle
Wheels
Rims
E13 TRS 30mm (Grey) + Hope Pro 4 (Black) 27.5
Tires
Maxxis Minion DHF 2.5 3C Exo / DHR II 2.4 Exo 27.5
Brakes
Brakes
SRAM Guide RE 200/200
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Burgtec RideWide Enduro 800mm
Grips
Strange Grappler Lock-On
Headset
Cane Creek 49mm for Tapered Steerer
Seat
Saddle
SDG Strange Bel Air III
Seatpost
SDG Tellis 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.3 mm | 1.24 mm | 1.24 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 763 mm | 785 mm | 805 mm | 829 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 131 mm | 130 mm | 131 mm | 131 mm |
| Stack | 600 mm | 609 mm | 609 mm | 627 mm |
| Reach | 453 mm | 470 mm | 491 mm | 506 mm |
| Top Tube Length | 601 mm | 621 mm | 641 mm | 661 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1202 mm | 1224 mm | 1244 mm | 1268 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 698 mm | 718 mm | 736 mm | 763 mm |
| Rear Travel | 130 mm | 130 mm | 130 mm | 130 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Five Evo RS is part of the Orange Five model. Orange launched 27 bikes of this model so far. Take a sneak peek at all Orange Five bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Orange Five Evo S 2022 has a starting price of 4447$. Orange Five EVO SE 2022 on the other hand is the most expensive at 7400$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2022 and its price was 6459$. Comparing this to the average Trail bike price, we see that the price is 133.85% more expensive.
Overview of components
Fork
Orange Five Evo RS 2022 bike is equipped with the RockShox Pike Ultimate fork, and has 140mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the RockShox Super Deluxe Ultimate 190×45 rear shock model, which has a travel of 130mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the Five Evo RS bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Five Evo RS is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Orange model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
