Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Custom Butted OS Aluminium Tube. Wheel Size: 700c.
Suspension Fork
Strange Full Carbon Flat Mount Disc
Drivetrain
Rear Derailleur
Shimano GRX RX812
Shift Levers
Shimano GRX RX600
Crank
FSA Omega 40t
Bottom Bracket
FSA
Chain
KMC 11spd
Wheels
Rims
DT Swiss G1800 700c
Tires
Maxxis Rambler 700x40 Tan
Brakes
Brakes
Shimano GRX RX600 / RX400 Hydraulic Disc
Cockpit
Grips
Strange EAV Gel Bar Tape Black
Headset
FPD 44mm / 56mm zerostack
Seat
Saddle
WTB Volt Steel
Seatpost
Strange Post 400 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.481 mm | 1.46 mm | 1.471 mm | 1.481 mm |
| Bottom Bracket Height | 419 mm | 419 mm | 419 mm | 419 mm |
| Front Center | 596 mm | 616 mm | 633 mm | 649 mm |
| Rake | -3 mm | -3 mm | -3 mm | -3 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 548 mm | 562 mm | 581 mm | 600 mm |
| Reach | 370 mm | 385 mm | 395 mm | 405 mm |
| Top Tube Length | 527 mm | 546 mm | 562 mm | 577 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1021 mm | 1041 mm | 1058 mm | 1075 mm |
| Bottom Bracket Drop | -70 mm | -70 mm | -70 mm | -70 mm |
| Standover Height | 762 mm | 776 mm | 796 mm | 812 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
RX9 Pro 700c is an Orange Rx9 model. Orange released 5 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Orange RX9 S 2023 has a starting price of 2679$. Orange RX9 RS 2023 on the other hand is the most expensive at 3812$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
RX9 Pro 700c components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on RX9 Pro 700c are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange RX9 Pro 700c is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
