Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Ultimate
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike Ultimate, 42mm offset
Rear Shock
RockShox Super Deluxe Ultimate, 190mm x 45mm
Drivetrain
Rear Derailleur
Shimano XT 12-speed
Front Derailleur
None
Shift Levers
Shimano XT 12-speed
Cassette
Shimano XT 10-51 tooth 12-speed
Crank
Hope Tech (silver)
Bottom Bracket
Hope Tech, 30mm (silver)
Chain
Shimano XT 12-speed
Chain Guide
None
Pedals
None included
Wheels
Front Hub
Hope Tech Pro 4 (silver)
Rear Hub
Hope Tech Pro 4 (silver)
Rims
e*thirteen TRS, 30mm inner width
Tires
Front: Maxxis Minion DHF 29"x2.5" WT, Rear: Maxxis Minion DHR II 29"x2.4" WT
Brakes
Brakes
Hope Tech 3 E4 (silver/black), 203mm/180mm rotors
Brake Levers
Hope Tech 3 E4 (silver/black)
Cockpit
Stem
Burgtec MK3 Enduro (silver), 42.5mm length
Handlebar
Burgtec RideWide Enduro, 800mm width
Grips
Orange Strange 130, single lock-on, 130mm length
Headset
Hope Tech (silver), 49mm for tapered steerer
Seat
Saddle
SDG Radar, cromo rail
Seatpost
SDG Tellis, 150mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.35 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Stack | 618 mm | 618 mm | 628 mm | 636 mm |
| Reach | 438 mm | 458 mm | 476 mm | 494 mm |
| Top Tube Length | 593 mm | 613 mm | 633 mm | 653 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1196 mm | 1216 mm | 1238 mm | 1260 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 688 mm | 707 mm | 734 mm | 760 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Stage Evo LE is an Orange Stage model. There are 43 bikes that carry this model name. Take a sneak peek at all Orange Stage bikes models from 2021, by clicking here.
Model range prices
Orange Stage EVO Pro 2021 is the cheapest bike model and costs 4300$. Orange Stage 6 XTR 2021 is the most expensive one and costs 7200$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The Stage Evo LE comes factory-installed with the RockShox Pike Ultimate fork. This has a travel range of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Stage Evo LE has a rear shock with a travel of 120mm. The model RockShox Super Deluxe Ultimate is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the Stage Evo LE model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
