Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Factory Float 34
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Occam AM 2018 Hydro Triple Butted 150mm travel 27.5 C-Boost 12x148 PF
Suspension Fork
Fox 34 Float Performance 150 3-Position QR15x110 Fox 34 Float Factory 150 FIT4 3-Pos-Adj QR15x110 Kashima
Rear Shock
Fox Float DPS Performance 3-Position Evol custom tune 210x55mm Fox DPX2 Factory 3-Pos Adjust Evol Kashima 210x55mm
Drivetrain
Rear Derailleur
SRAM NX Eagle
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX PG-1230 Eagle 11-50t 12-Speed
Crank
SRAM Descendant CNC Eagle Dub Boost 32t Rotor QX1 DM SRAM 32t Chainring (EXTRA)
Chain
SRAM NX Eagle 12-Speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Mach1 Klixx, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
Mach1 Klixx, 110x15mm Boost front, 148x12mm Boost rear
Rims
Mach1 Klixx 23c Tubeless Ready DT M-1900 Spline 30c TLR 15/110mm CL+Maxxis TLR Tires
Tires
Maxxis Ardent 2.40" FB 60 Tpi Maxxis High Roller II 2.40"TLR(Front)/Ardent 2,40"
Brakes
Brakes
Shimano MT501 BR500 Hydraulic Disc Shimano XT M8000 Hydraulic Disc
Brake Levers
Shimano MT500 Hydraulic
Cockpit
Stem
Race Face Ride
Handlebar
Orbea OC-II Riser 760mm Race Face Aeffect35 Riser 20/760mm+Aeffect R35 Kit
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal Custom Trail II 2043 HRN Selle Italia XR Trail
Seatpost
Race Face Aeffect Dropper 31.6x385/125mm Crank brothers Highline 31,6x425/150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.35 mm | 1.31 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 696 mm | 724 mm | 748 mm | mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 114 mm | 113 mm | mm |
| Stack | 578 mm | 588 mm | 597 mm | 610 mm |
| Reach | 399 mm | 424 mm | 443 mm | 465 mm |
| Top Tube Length | 556 mm | 583 mm | 605 mm | 630 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 432 mm | 470 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1114 mm | 1142 mm | 1166 mm | mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm | 13 mm |
| Standover Height | 706 mm | 734 mm | 761 mm | 778 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
OCCAM AM H30 completes the Orbea Occam model. 80 bikes variations carry this model name so far. Take a sneak peek at all Orbea Occam bikes models from 2018, by clicking here.
Model range prices
The most economical model, the Orbea OCCAM TR H50 2018 has a starting price of 2499$. Orbea OCCAM AM M-LTD 2018 on the other hand is the most expensive at 7999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Orbea OCCAM AM H30 price was 2999$. Comparing this to the average Enduro bike price, we see that the price is 20.01% lower.
OCCAM AM H30 components
Fork
Orbea OCCAM AM H30 2018 bike is equipped with the Fox Factory Float 34 fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is Fox Float DPS Performance 3-Position Evol, with a travel distance of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Orbea OCCAM AM H30 2018, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea OCCAM AM H30 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the OCCAM AM H30. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
