Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca Aero carbon OMR, monocoque construction,tapered 1-1/8" - 1,5", BB 386mm, powermeter compatible, internal cable routing, EC/DC compatible.
Suspension Fork
Orca Aero OMR carbon fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 R8050 SS
Front Derailleur
Shimano Ultegra Di2 R8050
Shift Levers
Shimano Ultegra R8050 Di2
Cassette
Shimano Ultegra R8000 11-28t 11-Speed
Crank
Shimano Ultegra R8000 34x50t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
KMC X11-EL
Wheels
Rims
Vision Team 35 Comp SL Clincher
Tires
Vittoria Rubino G2.0 Foldable 700x25c
Brakes
Brakes
Shimano Ultegra R8010
Cockpit
Stem
OC2 Road -8º
Handlebar
OC2 Road, reach 80mm, drop 125mm
Headset
FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Seat
Saddle
Prologo Dimension T4.0 size143 mm
Seatpost
Orbea Aero OMR
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.36 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.51 mm |
| Bottom Bracket Height | 269.5 mm | 269.5 mm | 269.5 mm | 271.5 mm | 271.5 mm | 271.5 mm | 271.5 mm |
| Front Center | 573 mm | 577 mm | 581 mm | 582 mm | 593 mm | 602 mm | 616 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 65 mm | 62 mm | 57 mm | 59 mm | 57 mm | 57 mm | 57 mm |
| Stack | 500 mm | 509 mm | 527 mm | 547 mm | 566 mm | 584 mm | 610 mm |
| Reach | 369 mm | 374 mm | 379 mm | 384 mm | 390 mm | 397 mm | 403 mm |
| Top Tube Length | 508 mm | 520 mm | 533 mm | 546 mm | 558 mm | 574 mm | 587 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 450 mm | 465 mm | 490 mm | 515 mm | 535 mm | 555 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 100 mm | 108 mm | 124 mm | 144 mm | 163 mm | 181 mm | 208 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 969 mm | 973 mm | 977 mm | 979 mm | 990 mm | 999 mm | 1013 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 727 mm | 741 mm | 762 mm | 781 mm | 805 mm | 823 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
ORCA AERO M20iTEAM is part of the Orbea Orca model. Orbea launched 214 bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Orbea ORCA M40 2020 is the most affordable bike of this model and has a price of 1799$. On the other hand, Orbea ORCA M11eLTD-D 2020, is the most expensive and costs 9599$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Aero bikes
If you want to purchase a solid Aero bike, it is important to know that the average cost is 4211$. However, even if your budget is less than the average, you might still be able to get a top-quality Aero bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2020 and its price was 4299$. In conclusion, this bike price is 2.09% more expensive than the price of the average Aero bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on ORCA AERO M20iTEAM are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea ORCA AERO M20iTEAM has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
ORCA AERO M20iTEAM comes in 7 sizes, that range from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, finding one for you shouldn’t be a problem.
