Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Direct Connect High Modulus Carbon, Tapered Headtube, Thru-Axles and CDS Internal Cable Routing
Suspension Fork
Full Carbon Monocoque 1-1/8" to 1.5" Taper, Thru-Axle with Post Disc Mounts
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra 10spd STI, Jagwire housing w/Stainless Slick Cables
Cassette
Shimano 10spd (11-34t)
Crank
Forged 2PC Compact 34/50t
Bottom Bracket
External Bearing
Chain
KMC X10
Pedals
Test Ride Pedals
Wheels
Front Hub
Joytech Alloy Disc 15mm, 32H, Thru-Axle
Rear Hub
Joytech Alloy Disc, 32H, 142x12mm Thru-Axle Cassette
Rims
Weinmann XC180 Double Wall 23mm Wide
Spokes
14g Stainless Steel
Tires
Clement Strada LGG 700x32c
Brakes
Brakes
TRP Spyre C dual actuated mechanical disc brakes, w/160mm rotors
Brake Levers
Shimano Tiagra STI
Cockpit
Stem
3D Forged Anti-Shock, 31.8, 90/100/110mm
Handlebar
Raleigh 200 Series Aero Ergo Flat Top Road, 31.8 with 10 Degree Flare, 40/42/44cm
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh 200 series Saddle
Seatpost
Anti-Shock 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.5 mm | 1.5 mm | 1.51 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 258 mm | 261 mm | 261 mm | 263 mm | 263 mm | 263 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 547 mm | 567 mm | 583 mm | 599 mm | 614 mm | 629 mm |
| Reach | 375 mm | 378 mm | 388 mm | 396 mm | 403 mm | 413 mm |
| Top Tube Length | 540 mm | 550 mm | 565 mm | 580 mm | 595 mm | 610 mm |
| Seat Tube Angle | 73 ° | 74 ° | 73.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 175 mm | 195 mm | 210 mm | 225 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 765 mm | 785 mm | 805 mm | 825 mm | 840 mm | 860 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Merit Sport belongs to the Raleigh Merit model. 8 bikes variations carry this model name so far. You can easily view all of the Raleigh Merit bikes models from 2017, here.
Model range prices
The most economical model, the Raleigh Merit 1 2017 has a starting price of 849$. Raleigh Merit Elite 2017 on the other hand is the most expensive at 2599$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2017 and its price was 1800$. Doing a quick comparison, we notice that Merit Sport price is 30.33% lower than the average cost of an Endurance bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Merit Sport components
Fork material
Merit Sport has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The Merit Sport 2017 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Merit Sport is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
