Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Fork SunTour -
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061, Raleigh "True Comfort" Geometry
Suspension Fork
SR Suntour M3030, 27.5"
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TX51
Shift Levers
Shimano EF-51 EZ Fire 8spd
Cassette
SRAM PG830 8spd (11-32t)
Crank
Shimano FC-M171 48/38/28t
Bottom Bracket
Sealed Cartridge 68/122
Chain
KMC HG40
Pedals
Raleigh Comfort Platform
Wheels
Front Hub
Joytech Alloy QR 32h
Rear Hub
Shimano32h Cassette
Rims
Weinmann XTB, 32h, 27.5"
Spokes
14g Stainless Steel, w/ Brass Nipples
Tires
Kenda K841A 27.5x1.95
Brakes
Brakes
Promax Alloy V-Brake
Brake Levers
Shimano EF-51
Cockpit
Stem
Alloy Quill 25.4, EXT:90mm, Adjustable Rise
Handlebar
Alloy 6061 Comfort Width: 640mm Rise: 50mm
Grips
Raleigh Comfort Grip
Headset
Threaded 1-1/8"
Seat
Saddle
Raleigh Comfort Plush
Seatpost
Alloy Micro Adjust Bootless Suspension 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.7 mm | 1.74 mm | 1.8 mm | 1.8 mm |
| Front Center | 607 mm | 623 mm | 638 mm | 654 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 73 mm | 74 mm | 72 mm | 83 mm |
| Stack | 614 mm | 642 mm | 670 mm | 700 |
| Reach | 362 mm | 369 mm | 372 mm | 388 mm |
| Top Tube Length | 567 mm | 582 mm | 597 mm | 612 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 160 mm | 190 mm | 220 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1051 mm | 1067 mm | 1082 mm | 1098 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 732 mm | 772 mm | 812 mm | 847 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Venture 4.0 is part of the Raleigh Venture model. Raleigh launched 12 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Raleigh Venture 2017 is the most economical model, with a starting price of 299$. Raleigh Venture 4.0 Step Thru 2017 on the other hand costs 449$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Comfort bikes
If you want to purchase a solid Comfort bike, it is important to know that the average cost is 360$. However, even if your budget is less than the average, you might still be able to get a top-quality Comfort bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2017 and its price was 449$. In conclusion, this bike price is 24.72% higher than the price of the average Comfort bike.
Overview of components
Fork
The Venture 4.0 comes factory-installed with the SunTour fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the Venture 4.0 bike is equipped with the aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
Raleigh Venture 4.0 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
