Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Series Custom Hydroformed Alloy. Threaded BB. Tapered Zerostack Headtube. Rack and Fender Mounts.
Suspension Fork
Suntour XCM-LO 29.100mm (XS: 80mm). SpeedLock / Fixed Rebound
Drivetrain
Rear Derailleur
Shimano Alivio 9spd
Front Derailleur
Shimano Acera 9spd 31.8mm
Shift Levers
Shimano Acera Rapid Fire 9spd
Cassette
Shimano HG200 11-34T 9spd
Crank
Shimano M371 170-175mm 42/32/22T
Bottom Bracket
FSA 7420
Chain
KMC X9 9spd
Wheels
Front Hub
Shimano RM33 / Centerlock / 32H
Rear Hub
Shimano RM33 / Centerlock / 32H
Rims
Wheeltech SX19 By WTB
Spokes
Stainless
Tires
Maxxis Sphinx 29\" x 2.1\"
Brakes
Brakes
Shimano M355 Hydraulic Disc 160mm
Brake Levers
Shimano M355
Cockpit
Stem
Rocky Mountain XC7 7° x 60-90mm
Handlebar
Rocky Mountain Zero6 Flat 31.8mm x 670mm x 6° Sweep
Grips
Rocky Mountain XC Kraton
Headset
FSA #57 Internal: ZS44 | ZS56mm
Seat
Saddle
WTB Volt
Seatpost
Rocky Mountain XC 27.2mm x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.61 mm | 1.51 mm | 1.48 mm | 1.45 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 637 mm | 630 mm | 652 mm | 676 mm | 699 mm |
| Rake | 53 mm | 44 mm | 43 mm | 42 mm | 43 mm |
| Trail | 83 mm | 88 mm | 89 mm | 90 mm | 89 mm |
| Stack | 603 mm | 621 mm | 620 mm | 634 mm | 648 mm |
| Reach | 382 mm | 386 mm | 410 mm | 429 mm | 446 mm |
| Top Tube Length | 556 mm | 576 mm | 598 mm | 621 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 355 mm | 394 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.25 ° | 70.25 ° | 70.25 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1084 mm | 1077 mm | 1099 mm | 1123 mm | 1146 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 725 mm | 744 mm | 758 mm | 782 mm | 814 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Fusion 920 belongs to the Rockymountain Fusion model. Rocky Mountain launched 35 bikes of this model so far. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Rocky Mountain Fusion 910 2016 is the most affordable bike of this model and has a price of 699$. On the other hand, Rocky Mountain Fusion 940 2016, is the most expensive and costs 999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2016 for 799$. Comparing the average cost of a Crosscountry bike to this one, you will see that Fusion 920 price is 138.42% lower.
Fusion 920 components
Fork
Rocky Mountain Fusion 920 2016 bike is equipped with the SunTour XCM fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Fusion 920 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fusion 920 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
