Santa Cruz Heckler S / Carbon CC / MX 2021
2021 E-bike
Estimate price |
9,249$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" / 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Pike Select
-
Groupset GX Eagle, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano 504Wh Integrated -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
174cm - 187cm
XL
184cm - 194cm
XXL
192cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Heckler S / Carbon CC / MX
Suspension Fork
RockShox Pike Select+, 140mm, 29"
Rear Shock
FOX Float Performance Elite DPS
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle Single Click, 12spd
Cassette
SRAM XG1275 Eagle 10-50T
Crank
Shimano EM600 Crank Arms, 165mm
Chain
SRAM GX Eagle 12 SPD
Chain Guide
E13 E-Spec+ AL
Wheels
Front Hub
DT 370 15x110 32H
Rear Hub
DT Swiss 370, 12x148, XD, 32h
Rims
RaceFace AR Offset 30 29" Rim (F) / RaceFace AR Offset 30 27.5" Rim (R)
Spokes
Sapim Race
Tires
Front: Maxxis Minion DHF 29"x2.5, 3C, MaxxGrip, EXO, TR, Rear: Maxxis Minion DHR II 27.5"x2.4", 3C, EXO+
Brakes
Brakes
SRAM Code R
Disk Rotors
Avid Centerline 200mm
Cockpit
Stem
Burgtec Enduro MK3 42mm
Handlebar
Santa Cruz Bicycles Carbon Di2 Riser
Grips
Santa Cruz Palmdale Grips
Headset
Cane Creek 40 IS Integrated Headset
Seat
Saddle
WTB Silverado Pro
Seatpost
SDG Tellis Dropper, 31.6
Motor & Battery
Motor
Shimano DU-EP800
Battery
Shimano 504Wh Integrated
Remote
Shimano E7000 Mode Switch
Charger
Shimano Battery Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.37 mm | 1.33 mm | 1.31 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 763 mm | 790 mm | 821 mm | 865 mm |
| Rake | 35 mm | 35 mm | 35 mm | 35 mm |
| Trail | 139 mm | 139 mm | 139 mm | 139 mm |
| Stack | 618 mm | 632 mm | 646 mm | 669 mm |
| Reach | 441 mm | 461 mm | 486 mm | 510 mm |
| Top Tube Length | 603 mm | 628 mm | 657 mm | 690 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 64.6 ° | 64.6 ° | 64.6 ° | 64.6 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 175 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1213 mm | 1240 mm | 1271 mm | 1306 mm |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm | 6 mm |
| Standover Height | 749 mm | 747 mm | 762 mm | 744 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 174 cm | 184 cm | 192 cm |
| Rider Max Height | 177 cm | 187 cm | 194 cm | 200 cm |
About this model
Heckler S / Carbon CC / MX belongs to the Santacruz E Heckler model. There are 48 e-bikes that carry this model name. You can easily view all of the Santacruz E Heckler e-bikes models from 2021, here.
Model range prices
The most economical model, the Santa Cruz Heckler R / Carbon CC / MX 2021 has a starting price of 7699$. Santa Cruz Heckler X01 RSV / Carbon CC / 27.5 2021 on the other hand is the most expensive at 12099$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 9249$. Doing a quick comparison, we notice that Heckler S / Carbon CC / MX price is 174.86% higher than the average cost of a Trail e-bike.
Overview of components
Fork
The fork installed on this bike is the RockShox Pike Select model. The travel on this model is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Santa Cruz Heckler S / Carbon CC / MX e-bike has the FOX Float Performance Elite DPS model installed, and has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Heckler S / Carbon CC / MX 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Heckler S / Carbon CC / MX comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Santa Cruz Heckler S / Carbon CC / MX e-bike has 4 sizes, in the range of 165 cm – 200 cm (5.41 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Santa Cruz model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
