Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Marzocchi Bomber Z2
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 172cm
MD
170cm - 180cm
LG
178cm - 186cm
XL
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SERIES 3 CUSTOM BUTTED AND HYDROFORMED 6013 ALLOY FRONT TRIANGLE AND SWINGARM. Headtube: ZS44-ZS56 tapered headtube. Bearings: 37mm main pivot bearings / 28mm linkage bearings. Linkage: Convertible CNC linkage included for both mullet and 29er setups. Suspension: Signature TRL suspension design. Cable Routing: Internal. Axle: 12 x 157mm SuperBoost dropout system. Rear Travel: 130mm.
Suspension Fork
MARZOCCHI BOMBER Z2. Travel: 130mm. Technology: Tapered steerer / rebound adjust / sweep adjust rail damper. Axle: QR 15x110 Boost. Rake: 44mm.
Rear Shock
FOX FLOAT DPS PERFORMANCE. Adjustment: EVOL air damper / rebound adjust / 3 position compression. Length / Stroke: 210 x 50.
Drivetrain
Rear Derailleur
SHIMANO SLX. Model: M7100 SGS Shadow Plus. Speed: 12 speed.
Shift Levers
SHIMANO DEORE. Model: M6100 Rapidfire Plus 2-way release. Speed: 1x12 speed.
Cassette
SHIMANO DEORE. Model: M6100. Speed: 12 speed. Ratio: 10-51T.
Crank
SHIMANO DEORE. Model: FC-M6130. Chain Ring: 32T. Crank Length: 170mm / 56.5mm.
Bottom Bracket
SHIMANO BB52 73MM.
Chain
KMC X12.
Wheels
Front Hub
KT. Front: DHF122 sealed bearing 32H. Rear: DHR2S5 sealed bearing 32H. Brake Fitting: 6-bolt. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12 x 157 SuperBoost. Hole: 32H.
Rear Hub
KT. Front: DHF122 sealed bearing 32H. Rear: DHR2S5 sealed bearing 32H. Brake Fitting: 6-bolt. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12 x 157 SuperBoost. Hole: 32H.
Rims
DT SWISS M442. Hole: 32H. Size: 29'' Front / 29'' Rear (Sizes Large / XL) 29'' Front / 27.5'' Rear (Sizes Small / Medium). Tubeless Ready: Yes.
Spokes
DOUBLE-BUTTED STAINLESS STEEL.
Tires
MAXXIS MINION DHRII. Model: EXO TR. Size: 29 x 2.4 Front & Rear (Sizes Large / XL) / 29 x 2.4 Front / 27.5 x 2.3 Rear (Sizes Small / Medium).
Brakes
Brakes
SHIMANO DEORE. Model: BR-M6100. Brake Type: Hydraulic two piston. Rotor Size: 180/180mm.
Brake Levers
SHIMANO DEORE.
Cockpit
Stem
RACEFACE CHESTER 35. Length: 50mm. Rise: 6 degree. Clamp: 35mm. Type: Ahead.
Handlebar
RACEFACE CHESTER 35. Width: 780mm. Rise: 20mm. Bar Bore: 35mm.
Grips
ODI ELITE MOTION.
Headset
PRESTINE PT-F13.
Seat
Saddle
SARACEN CUSTOM CRMO MTB.
Seatpost
KS RAGE I. Routing: Internal. Size: 30.9mm. Travel: 150mm, 125mm on size small. Lever: Westy remote.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.26 mm | 1.23 mm | 1.19 mm |
| Front Center | 772 mm | 801 mm | 832 mm | 864 mm |
| Rake | 48 mm | 47 mm | 47 mm | 47 mm |
| Trail | 122 mm | 123 mm | 123 mm | 123 mm |
| Stack | 589 mm | 598 mm | 612 mm | 626 mm |
| Reach | 449 mm | 474 mm | 499 mm | 524 mm |
| Top Tube Length | 592 mm | 619 mm | 647 mm | 676 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 360 mm | 410 mm | 460 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1204 mm | 1233 mm | 1264 mm | 1296 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 726 mm | 726 mm | 725 mm | 725 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 170 cm | 178 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 186 cm | 196 cm |
Model Overview
Ariel 30 is part of the Saracen Ariel model. 21 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Saracen Ariel Junior 2023 is the cheapest bike model and costs 2313$. Saracen Ariel 60 Elite 2023 is the most expensive one and costs 5357$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 3043$. Comparing the average cost of a Trail bike to this one, you will see that Ariel 30 price is 10.17% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Ariel 30 components
Fork
Saracen Ariel 30 2023 bike is equipped with the Marzocchi Bomber Z2 fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Saracen Ariel 30 bike has the FOX FLOAT DPS PERFORMANCE. Adjustment: EVOL model installed, and has a travel of 130mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the Ariel 30 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Saracen Ariel 30 bike has 4 sizes, in the range of 154 cm – 196 cm (5.05 ft – 6.43 ft). In short, you can easily find one that suits you.
Dropper post
Saracen Ariel 30 comes with a dropper post. Therefore, climbing or descending will be a breeze.
