Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 180mm -
Fork Fox Performance Elite Float 38
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 172cm
MD
170cm - 180cm
LG
178cm - 186cm
XL
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SERIES 3 CUSTOM BUTTED AND HYDROFORMED 6013 ALLOY FRONT TRIANGLE AND SWINGARM. Headtube: ZS44-ZS56 tapered headtube. Bearings: 37mm main pivot bearings / 28mm linkage bearings. Suspension: Signature TRL suspension design. Cable Routing: Internal. Axle: 12 x 157mm SuperBoost dropout system. Rear Travel: 180mm.
Suspension Fork
FOX 38 PERFORMANCE ELITE. Travel: 180mm. Technology: Tapered steerer / HSC LSC HSR LSR adjust / Grip2 damper. Axle: 15x110 Boost. Rake: 44mm.
Rear Shock
FOX FLOAT DHX2 PERFORMANCE. Adjustment: 2-position adjust. Length / Stroke: 250 x 70.
Drivetrain
Rear Derailleur
SHIMANO XT. Model: M8100 SGS Shadow Plus. Speed: 12 speed.
Shift Levers
SHIMANO SLX; M7100 RAPIDFIRE PLUS 2-WAY RELEASE. Model: 1x12 speed.
Cassette
SHIMANO SLX. Model: M7100. Speed: 12 speed. Ratio: 10-51T.
Crank
SHIMANO SLX. Model: FC-M7130. Chain Ring: 32T. Crank Length: 170mm / 56.5mm.
Bottom Bracket
SHIMANO BB-MT800 73MM.
Chain
KMC X12.
Wheels
Front Hub
SHIMANO. Front: SLX HB-M7110 32H. Rear: SLX FH-M7130 32H. Brake Fitting: Centre-lock. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12 x 157 SuperBoost. Hole: 32H.
Rear Hub
SHIMANO. Front: SLX HB-M7110 32H. Rear: SLX FH-M7130 32H. Brake Fitting: Centre-lock. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12 x 157 SuperBoost. Hole: 32H.
Rims
DT SWISS E532. Hole: 32H. Size: 27.5''. Tubeless Ready: Yes.
Spokes
DOUBLE-BUTTED STAINLESS STEEL.
Tires
MAXXIS MINION DHRII. Model: EXO TR. Size: 27.5 x 2.4.
Brakes
Brakes
SHIMANO SLX. Model: BR-M7120. Brake Type: Hydraulic four piston. Rotor Size: 203/203mm.
Brake Levers
SHIMANO SLX.
Cockpit
Stem
RACEFACE CHESTER 35. Length: 40mm. Rise: 0 degree. Clamp: 35mm. Type: Ahead.
Handlebar
RACEFACE ATLAS 35. Width: 820mm. Rise: 35mm. Bar Bore: 35mm.
Grips
ODI ELITE MOTION.
Headset
PRESTINE PT-F13.
Seat
Saddle
SARACEN CUSTOM CRMO MTB.
Seatpost
KS RAGE I. Routing: Internal. Size: 30.9mm. Travel: 170mm, 150mm on size small. Lever: Westy remote.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 769 mm | 798 mm | 830 mm | 862 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 136 mm | 136 mm | 136 mm | 136 mm |
| Stack | 596 mm | 604 mm | 618 mm | 631 mm |
| Reach | 429 mm | 454 mm | 479 mm | 504 mm |
| Top Tube Length | 574 mm | 601 mm | 629 mm | 657 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 360 mm | 360 mm | 410 mm | 460 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1201 mm | 1230 mm | 1262 mm | 1294 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm | 14 mm |
| Standover Height | 729 mm | 729 mm | 730 mm | 730 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 170 cm | 178 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 186 cm | 196 cm |
Model Overview
Ariel 80 Pro belongs to the Saracen Ariel model. Saracen released 21 bikes variations of this model so far. Take a sneak peek at all Saracen Ariel bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Saracen Ariel Junior 2023 has a starting price of 2313$. Saracen Ariel 60 Elite 2023 on the other hand is the most expensive at 5357$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Saracen Ariel 80 Pro price was 4261$. If we compare this with the average Enduro bike cost we notice that the price is 18.39% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The Fox Performance Elite Float 38 is included from the factory. It has a travel distance of 180mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Saracen Ariel 80 Pro bike has the FOX FLOAT DHX2 PERFORMANCE. Adjustment: 2-position adjust. Length / Stroke: 250 x 70. model installed, and has a travel of 180mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the Ariel 80 Pro bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Saracen Ariel 80 Pro is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 196 cm (5.05 ft – 6.43 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Saracen Ariel 80 Pro includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
